Planning a service for your Discovery 4? Before ordering filters, engine oil or an automatic gearbox service kit, check exactly which engine and transmission are fitted. Discovery 4 models can require different products depending on the engine, DPF and gearbox specification.

The three main details to confirm are:

• Engine size and type.
• Whether the vehicle has a diesel particulate filter (DPF).
• Whether it has a six-speed or eight-speed automatic gearbox.

Your registration number is a useful starting point, but the full VIN provides a more reliable compatibility check. This is particularly important for vehicles registered close to a specification change or those that have been imported or modified.

Choosing the correct engine service kit

An engine service kit normally contains the filters required for routine servicing. Some kits also include engine oil and a replacement drain plug, but the contents vary, so check the individual product description before ordering.

For diesel models, the oil must meet the specification required by the engine and its emissions equipment. Viscosity alone is not enough: two oils marked 5W-30 may have different specifications and approvals.

DA6086COM for Discovery 4 3.0 diesel models with a DPF

The DA6086COM engine service kit with 5W-30 oil is listed for Discovery 4 3.0 TDV6 and SDV6 diesel models fitted with a DPF.

The kit includes:

• Six one-litre bottles of 5W-30 engine oil.
• Oil filter.
• Air filter.
• Fuel filter.
• Cabin filter.
• Replacement oil drain plug with rubber seal.

Always check the live product listing for the latest contents and compatibility information. Follow the correct filling and oil-level checking procedure for your vehicle rather than assuming that the entire quantity supplied must be used.

If your Discovery 4 has a different engine, browse our Discovery 4 service kits and filters to find the appropriate option.

Choosing the correct automatic gearbox service kit

Discovery 4 models were fitted with both six-speed and eight-speed automatic gearboxes. Their service kits, filters, sumps and transmission fluids are different and cannot be interchanged.

Do not identify the gearbox from the engine badge or DPF status. If you are unsure which transmission is fitted, check the VIN and vehicle specification before ordering.

DA2142KITRAV for the six-speed gearbox

The DA2142KITRAV automatic gearbox service kit with Ravenol ATF is designed for applicable early Discovery 4 models fitted with the ZF six-speed automatic gearbox. It is not suitable for vehicles with the later eight-speed transmission.

The kit includes:

• Easy-change metal gearbox sump.
• Separate replacement filter.
• Sump gasket.
• Replacement sump bolts.
• Seven litres of Ravenol ATF 6HP transmission fluid.

The easy-change conversion replaces the original plastic sump and integrated filter with a metal sump and separate filter. This makes subsequent filter replacement more straightforward.

DA3383 for the eight-speed gearbox

The DA3383 eight-speed automatic gearbox sump, filter and Ravenol fluid kit is listed for Discovery 4 models from 2011 to 2016 fitted with the ZF 8HP70 eight-speed automatic transmission.

The kit includes:

• Replacement filter pan assembly.
• Seven litres of Ravenol transmission fluid.
• Replacement screws and plug.

This kit is not suitable for the earlier six-speed gearbox. Registration year alone may not identify the transmission conclusively, so check the vehicle specification before ordering.

What else should be checked during a service?

An engine or gearbox service kit only covers the parts included in that package. It does not replace the vehicle’s complete maintenance schedule.

Depending on the vehicle’s mileage and service history, other items may also require inspection or replacement, including:

• Auxiliary and timing belts.
• Brake fluid.
• Coolant.
• Differential and transfer box oils.
• Brake components.
• Suspension and steering components.
• Battery and charging system.

For more information about engine servicing, see our Discovery 4 3.0 diesel oil and maintenance guide.

Before ordering your Discovery 4 service parts

1. Confirm the engine: Check the engine size and type rather than relying on the trim level.
2. Check the DPF requirement: Make sure the engine oil meets the specification required by the vehicle.
3. Identify the gearbox: Establish whether the vehicle has the six-speed or eight-speed automatic transmission.
4. Read the kit contents: Check whether oil, filters, seals, plugs and fasteners are included.
5. Check availability: Allow for any additional supplier lead time shown on the product page.

Automatic gearbox servicing requires the correct filling procedure and fluid-level checks. If you do not have the required workshop information, equipment or experience, the work should be carried out by a suitably qualified specialist.

Find the right Discovery 4 service kit

JGS4x4 is an independent UK supplier of parts and accessories for Land Rover vehicles. Browse our Discovery 4 service kits and filters, or email sales@jgs4x4.co.uk with your registration number, full VIN and the products you are considering.

Checking compatibility before ordering is much easier than discovering that a kit is incorrect once the vehicle is in the workshop.
