Heater Matrix for Discovery 1 and Range Rover Classic | STC250

Replacement heater matrix for the cabin heating system on non-air-conditioned Range Rover Classic and early Discovery 1 models.
The heater matrix sits inside the heater box and transfers engine heat to warm the cabin air. Over time, the original matrix can leak or become blocked, resulting in poor heater performance or coolant loss.

Features:

Direct replacement for the original heater matrix on non-A/C models

Restores effective cabin heating and demisting

Aluminium core with plastic end tanks

Fitting Notes:

Range Rover Classic: VIN EA344072 to LA647644 (approx. 1988–1994) – no air conditioning

Discovery 1: up to VIN MA081991 (approx. 1989–1994) – no air conditioning

Not suitable for vehicles with factory-fitted air conditioning or climate control (use STC3262 or BTP1764 instead).

Drain and refill coolant after fitting; dash/heater box removal required.

Vehicle Compatibility

Range Rover Classic: 1988–1994, VIN EA344072–LA647644, non-A/C models only

Discovery 1: up to 1994, VIN to MA081991, non-A/C models only

Replaces / Supersedes

STC770, RTC6366
